KINGJET KJ-180UV 1.8m Roll to Roll UV Printer LED Printer





KINGJET KJ-180UV 1.8m Roll to Roll UV Printer LED Printer

Equipped with Ricoh GH2220 prient head,can directly print on different kinds of soft film. Media Type:PP,vinyl sheet indoor,light box cloth,drawing paper canvas,vinyl,reflective material,etc.



Inquire Now Next Product


KINGJET KJ-180UV 1.8m Roll to Roll UV Printer LED Printer

Our breakthrough UV technology addresses durability issues related to abrasion and solvents and also provides more effective,opaque white ink performance. This UV printing process is great for a very wide variety of commercial and industrial applications.



Uniquer Technology


Control Panel

Simple And Convenient,with Led Screen.
Easily Switch to different Interfaces.
Easily Turn or Off.


Small Cariage Form

Full Alumunium carriage frame ensure accurate Printing.
Automatic Adjust carriage height for different materials.
Proffesional positive UV damper ensure stable ink supply.
Anti-collision sensor.


Cylinder Clampe

Printing Options, Adjustable Spacing.
Can Printing Bottle,mug,Glass Bottlesand Other Cylindrical Objects.


Ink Bottle

First grade ink bottle.
0 Colors: CMYKLcLM+White+Vanish.
Low ink Volume alarm function equipped.


Leadshine motor

Integrated design, smaller size, lower noise and heating.
Strong anti-interference capability, smoother operation.


Intelligent ink scraping design

Automatically printhead cleaning and moisturizing.
Push-pull capping system design, can quickly reset to original position.


Honosoft carriage board

Mature and stable control system.
Carriage Board with fan cooler.
ensure long time & stable working.



Specifications

Model KINGJET KJ-180UV GH2220 PRINTER
Printhead Silicon based Ricoh GH2220 print head
Number of Printhead 4head                                                    8 head
Printing Speed 6pass                                                    12sqm/h                                                 24sqm/h
8pass                                                    8sqm/h                                                    16sqm/h
12pass                                                 6sqm/h                                                    12sqm/h
16pass                                                 4sqm/h                                                    8sqm/h
Maximum Print Width 1800mm
Printing Resolution 720×900　720×1200 (DPI)
Ink Type                                                                        UV Ink
Color                                                                       4 colors（K, C, M, Y)
ink Supply System                                              digital Ink Pressure System
Media Width 1880mm（74“）
Media Type PP, vinyl sheet indoor, light box cloth, drawing paper canvas, vinyl, reflective material
Print head Height 2-8mm Above Media step less Adjustable
Heating System Intelligent embedded heating system
Media Adsorption System Suction fan sucking step less adjustment
Auto Media System Equipped（Max Media Weight 60kg）
Digital Ink press system Ink Press Function & Moisturizing System
Clamp Combined anti-warping Clamps
Auto take up system 60kg heavy type take-up system
Print Interface Hi-USB2.0
RIP software Photoprint, Maintop
Input power AC220V,50Hz / 60Hz 800W- 2500W
Working environment Temperature：18-32℃ 　　Humidity：46-65%
Machine Dimension L3180xW850xH1470mm; Net Weight:450Kgs
Package Dimension L3350xW690xH740mm;Gross Weight:540Kgs
