KingJet Industrial Printing Machine

Using high speed Konica 1024i solvent printhead, the KINGJET KJ-3208P solvent printer can print at speeds of up to 480 sqmh.

Inquire Now Next Product

To meet the needs of printnig speed & precision, KINGJET KJ-3208P use KONICA MINOLTA 1024i print head, deliver high precision prints more efficiently. New printing technology make it possible to print 1 PASS & 480 sqm/h max speed. New industrial frame All aluminum beam 400W Panasonic AC servo motor system BYHX board Constant heating system High efficiency drying system

Detail Dislay

Alumunium Girder & Platform

High precision & durable printing.

Elevation Type Capping Station

New design capping system, more durable.

Mute guide rails

high pricison & smooth operation to ensure perfect quality output.

Infrared & Fan Drying System

High efficency drying system,printing continuously.

Feeding & Take-up System

Constant tension,ensure accurate & smooth operation.

Application

Outdoor Flex Banner

Using high-quality, cost-effective Kingjet konica inks, plus the newest konica minolta printhead texhnology to fire droplets precisely and efficiently, KJ-3208G is ideal for banner production. KJ-3208G output banners about 240 sqm/h, without sacrificing print quality.

Vehicle Wraps

Full wraps can be produced with high speed and quality. An integrated heater system and fans helps prints dry quickly so you can move on to lamination and finishing, and deliver superior results in no time – every time.

Outdoor Posters and Backlit Displays

Whether you're cranking out thousands of posters or producing a limited run on specialty material, the KJ-3208G stun images on a range of coated and uncoated media, including papers for posters and film for backlit displays.

Outdoor Mesh

With flying printing speed, KJ-3208G is the king of performance, especially for outdoor large format advertisements. It's easy for printing, no matter how busy business.

Application

Outdoor Flex Banner

Using high-quality, cost-effective Kingjet konica inks, plus the newest konica minolta printhead texhnology to fire droplets precisely and efficiently, KJ-3208G is ideal for banner production. KJ-3208G output banners about 240 sqm/h, without sacrificing print quality.

Vehicle Wraps

Full wraps can be produced with high speed and quality. An integrated heater system and fans helps prints dry quickly so you can move on to lamination and finishing, and deliver superior results in no time – every time.

Outdoor Posters and Backlit Displays

Whether you're cranking out thousands of posters or producing a limited run on specialty material, the KJ-3208G stun images on a range of coated and uncoated media, including papers for posters and film for backlit displays.

Outdoor Mesh

With flying printing speed, KJ-3208G is the king of performance, especially for outdoor large format advertisements. It's easy for printing, no matter how busy business.

Specifications

Model	KJ-3208P
Max.Printing Width	3200mm (10.5ft)
Printhead	KM512i-30PL-8H
Output Speed	2Pass 240m²/h
Printing Resolution	480x360dpi 2pass 240 ㎡/h 480x540dpi 3pass 180㎡/h 480x720dpi 4pass 120㎡/h
Ink	KINGJET solvent ink, 4 Colors( C , M , Y , K )
Ink Supply System	Low Ink Detector, Auto or Manual Ink Supply System
Ink Capacity	5L Per Main Tank of Each Color
Media Width	3300mm (10.8ft)
Media Type	Vinyl,Flex,Polyester,Back-lit Film, Window Film,etc
Equipped	Auto Media Feeding System (Max.Media Weight:120KG) Pre-heating & Drying System
Clamp	Equipped
Print Interface	USB2.0
Printhead Height	2 to 4 mm Above Media Adjustable
RIP Software	Photoprint, Maintop
Input Powe	AC 220V ,50Hz ,4500W
Operation Environment	Temperature: 20~28℃ Humidity: 40%~60%
Machine Size	L4650 x W884 x H1303mm; Net Weight: 780Kgs (1,499lbs)
Package Dimension	L4890 x W1060 x H1650mm; Gross Weight: 1000Kgs (1,984lbs);
