KINGJET 1.8M Roll to Roll UV Printer KJ-180UV

Using silicon based Ricoh GH2220 print head, equipped with high resolution guide rail, KJ-180UV roll to roll printer can directly print on different kinds of soft film.

Inquire Now Next Product

High Resolution Guide Rail Japan Imported LED UV lamp Powerful functions boards system Moisture ink absorption system Digital control ink press cleaning system

Uniquer Technology

Control Panel

Simple And Convenient,with Led Screen.
Easily Switch to different Interfaces.
Easily Turn or Off.

Small Cariage Form

Full Alumunium carriage frame ensure accurate Printing.
Automatic Adjust carriage height for different materials.
Proffesional positive UV damper ensure stable ink supply.
Anti-collision sensor.

Cylinder Clampe

Printing Options, Adjustable Spacing.
Can Printing Bottle,mug,Glass Bottlesand Other Cylindrical Objects.

Ink Bottle

First grade ink bottle.
0 Colors: CMYKLcLM+White+Vanish.
Low ink Volume alarm function equipped.

Leadshine motor

Integrated design, smaller size, lower noise and heating.
Strong anti-interference capability, smoother operation.

Intelligent ink scraping design

Automatically printhead cleaning and moisturizing.
Push-pull capping system design, can quickly reset to original position.

Honosoft carriage board

Mature and stable control system.
Carriage Board with fan cooler.
ensure long time & stable working.

Directly print on PP, vinyl sheet indoor, light box cloth, drawing paper canvas, vinyl, reflective material.x

Specifications

Model	KINGJET KJ-180UV GH2220 PRINTER
Printhead	Silicon based Ricoh GH2220 print head
Number of Printhead	4head 8 head
Printing Speed	6pass 12sqm/h 24sqm/h 8pass 8sqm/h 16sqm/h 12pass 6sqm/h 12sqm/h 16pass 4sqm/h 8sqm/h
Maximum Print Width	1880mm
Printing Resolution	720×900　720×1200 (DPI)
Ink	Type UV Ink Color 4 colors（K, C, M, Y) ink Supply System digital Ink Pressure System
Media Width	1880mm（74“）
Media Type	PP, vinyl sheet indoor, light box cloth, drawing paper canvas, vinyl, reflective material
Print head Height	2-8mm Above Media step less Adjustable
Heating System	Intelligent embedded heating system
Media Adsorption System	Suction fan sucking step less adjustment
Auto Media System	Equipped（Max Media Weight 60kg）
Digital Ink press system	Ink Press Function & Moisturizing System
Clamp	Combined anti-warping Clamps
Auto take up system	60kg heavy type take-up system
Print Interface	Hi-USB2.0
RIP software	Photoprint, Maintop
Input power	AC220V,50Hz / 60Hz 800W- 2500W
Working environment	Temperature：18-32℃ 　　Humidity：46-65%
Machine Dimension	L3180xW850xH1470mm; Net Weight:450Kgs
Package Dimension	L3350xW690xH740mm;Gross Weight:540Kgs
