KINGJET KJ-3202E large format eco solvent printer for flex banner/vinyl/wall sticker printing machine

Equipped with 2 Epson DX5 print head，printing resolution is 1440dpi.
Media Type：Car sticker / Lamp cloth / PP / Coated banner / Vinyl etc.

Inquire Now Next Product

KINGJET KJ-3202E Large Format Eco Solvent Printer For Flex Banner/Vinyl/Wall Sticker Printing Machine

Meet the new KJ-3202E&KJ-3204S large-format digital printer. With Epson DX5/XP600 print heads and a rigid new industrial design, productivity and quality are built in. So are big-time savings. High-volume, low-maintenance printing and bold, exciting colors with higher profit margins.

Structure Display

Detail Dislay

Alumunium Girder & Platform

High precision & durable printing.

Elevation Type Capping Station

New design capping system, more durable.

Mute guide rails

high pricison & smooth operation to ensure perfect quality output.

Infrared & Fan Drying System

High efficency drying system,printing continuously.

Feeding & Take-up System

Constant tension,ensure accurate & smooth operation.

Application

Outdoor Flex Banner

Using high-quality, cost-effective Kingjet konica inks, plus the newest konica minolta printhead texhnology to fire droplets precisely and efficiently, KJ-3208G is ideal for banner production. KJ-3208G output banners about 240 sqm/h, without sacrificing print quality.

Vehicle Wraps

Full wraps can be produced with high speed and quality. An integrated heater system and fans helps prints dry quickly so you can move on to lamination and finishing, and deliver superior results in no time – every time.

Outdoor Posters and Backlit Displays

Whether you're cranking out thousands of posters or producing a limited run on specialty material, the KJ-3208G stun images on a range of coated and uncoated media, including papers for posters and film for backlit displays.

Outdoor Mesh

With flying printing speed, KJ-3208G is the king of performance, especially for outdoor large format advertisements. It's easy for printing, no matter how busy business.

It fit for both outdoor and indoor advertisement, such asflex banner for billboards, vinyl sticker for exhibition and car wrap,pp paper for poster and roll up stand, photo paper, one way vision for window graphic,etc

Specifications

Model	KINGJET 3202E Eco Solvent Printer
Printhead	EPSON DX5 Print Head
Media Width	3200mm
Printing Resolution	4PASS 40㎡ 6PASS 30㎡ 8PASS 22㎡
RIP Software	Maintop, Photoprint
Printing Ink	Eco-solvent ink, Waterbased ink, Sublimation ink
Color	4 colors(K, C, M, Y)
Ink Supply System	Auto Cleaning Capping System
Media Type	PP, vinyl, light box cloth, flex, canvas, leather, reflective material etc.
Printhead Height	2-8mm Above Media Adjustable
Heating System	Intelligent Embedded Heating System
Media Adsorption	Suction Fan Sucking Step Less Adjustment
Auto Media System	Equipped(Max Media Weight 60kg)
Capping&Moisturizing	Auto Capping System&Moisturizing System
Clamp	Combined Anti-warping Clamps
Take Up System	60kg Heavy Type Auto Take-up System
Print Interface	Hi-USB 2.0
Input Power	AC220V,50HZ/60HZ,800W-2500W
Working environment	Temperature: 18-32℃ Humidity: 46%-65%
Machine Dimension	L4550W1000H1600mm
Package Dimension	L4590W1015H1500mm
Net Weight/Gross Weight	680KGS/800KGS

KINGJET KJ-3202E large format eco solvent printer
